4 series seamless aluminum tube

Brand : 4032

Features : It can be strengthened by heat treatment, has medium plasticity in annealing, just quenching and hot state, has good spot welding properties, and has a tendency to form intergranular cracks when using gas welding and argon arc welding, etc.

Applications : aircraft structures (skin, frame, rib beam, bulkhead, etc.), aircraft, ships, transportation, rivets, missile components, truck wheels, propeller components, etc.

Special services : nationwide sales, free samples, free door-to-door delivery, customizable with drawings and samples

Share to:

Product Details

4032Aluminum Chemical Composition
Cu Si Fe Mn Mg Zn Cr Ti Ni Al
0.5-1.3 11-13.5 ≤1.0 ≤0.05 0.8-1.3 ≤0.25 ≤0.1 ≤0.05 0.5-1.3 Remainder
4032Aluminum Bar Mechanical Properties
Werkstoff-zustand RmMPa Rp0,2MPa A50 mm% min. HBW Typischer Wert
T62 ≥360 ≥290 ≥2.5% /
Aluminium and aluminium alloys – Chemical compositionand form of wrought productsPart 3: Chemical compositionEnglish version of DIN EN 573-3
Aluminium and aluminium alloys-Cold drawn rod/bar and tube Part 2 Mechanical properties:DIN EN 754-2-2008
Aluminium and aluminium alloys-Extruded rod/bar,tube and profiles Part 2:Mechanical properties:DIN EN_755-2-2008
Aluminium and aluminium alloyextruded rods/bars, round bars Chemical composition+Mechanical properties:ASTM B211M-2001
Aluminium and aluminium alloy extruded rods/bars,tubes and profles Chemicalcomposition+Mechanical properties:ASTM B221
Wrought Aluminium and aluminium alloyextruded profles Chemical composition+Mechanical properties:JIS H4100-2006
Wrought Aluminium and aluminium alloy extruded rods/bars Chemical composition+Mechanical properties:JIS H4040-2006
Aluminium and aluminium alloy extruded rods/bars Chemical composition:GB/T3190-2008
Aluminium and aluminium alloy extruded rods/bars Mechanical properties:GB/T3191-2010
